KT-SR805 24V 50MA ABS Safety Edge Switch Controller Safety Relay

1. General product information

2. Product commercial terms

Safety Edge Switch controller safety edge switch controller safety edge switch controller safety edge switch controller safety edge switch controller

3. Product introduction

• Quick Detail:

  Safety Relay

  Connect the secure edge to the device, allowing the device to be controlled

• Description:

  Connect the secure edge to the device, allowing the device to be controlled，Ensure the normal operation of machinery and guarantee the safety of personnel.

• Applications:

  Emergency stop/Safety switch PNP safety switch/PNP safety light curtain/2-wire Safety contact edge(safety mat)with resistor/2-wire Safety contact edge(safety mat)without resistor/4-wire Safety mat)/Two hands switch.

• Specifications:

  Edge groups	1 group
  Disconnected independent output	not supported
  Rated voltage	DC 24V
  Voltage range	DC 12-36V
  Maximum current	50mA
  Safe output	DC24V 3A
  Load resistance	3K ohms -30k ohms
  Trigger resistance	0 ohms -500 ohms
  Durability	1 million cycles
  Environmental temperature for use	- 20~55°C
  Output	24v 30mA
  Appearance dimensions	L95*W25*H47mm
  Weight	50g ± 10%
  Operating environment humidity	85% RH (no condensation)

• Competitive Advantage:

  • Switching from normally open signal to normally closed signal for safe edge contact improves product safety.
  • Safety edge breakage detection alarm, monitoring system for short circuit or open circuit, and displaying its status with LED indicator lights.
  • Support traditional normally open and series resistor safe edge connections· Output normally open and normally closed signals are optional· Standard 35mm rail installation.
  • The internal resistance supports IKQ-12K Ω, and the maximum trigger resistance supports 500 Ω· 12V-36V wide voltage input.
  • Support 1-2 sets of secure edge touches and independent output when disconnected.
